Set Up
All TelePatch systems will be shipped in “Normal” mode. There is therefore, no need to instruct
users on how to select the “Normal” mode. The following instructions describe the steps and
screens for selecting “Test” mode. To apply the “Test” mode:
• Tap “Normal”.
• Tap “Test” on drop down menu.
If there are additional settings changes desired, repeat the steps above
for Pacemaker and Protocol. After all the correct settings have been
chosen,
• Tap “Accept Settings”
An example of a test result screen for the Skin Prep is provided below.
Skin Prep Test Result
For additional standard procedure setup instructions, go to PATIENT PREPARATION.
If a mistake is made during the procedure setup process, the set up can Start Over.
“START OVER” WILL ERASE ALL PREVIOUS SETTING SELECTIONS IN ORDER TO START THE
ENTIRE PROCEDURE SETTINGS PROCESS FROM THE VERY BEGINNING.
Start Over:
• Tap “Start Over” button.
This will erase all previous setting selections in order to start the entire procedure settings
process over from the very beginning:
● Protocol: The protocol is an integral part of the auto capture capability. It may be
defined as a set of guidelines that the ECG analysis algorithm uses in identifying
clinically-significant events. For example, the normal heart rate in Standard protocol is
60-100 bpm.
●
Pediatric Protocol: this range is 80-150 bpm. Therefore, the TelePatch System would not
trigger to generate recordings for heart-rate events of 140 bpm if the protocol had been
set to Pediatric, but would trigger if it had been set to Standard.
● For additional standard procedure setup instructions, go to PATIENT PREPARATION.
Tele
Patch™ Cardiac Monitor PM750
USER MANUAL - UTM0000701-05E
| APRIL 4, 2019
42
