a) Trolley plate
b) Knurled screw
3 Installaon of the medin-NC3® – Condions
Before pung the medin-NC3® into service, the following must be borne in mind:
Figure 3-1: a) Trolley plate; b) Knurled screw
3.1 Assembly
Warning:
- The medin-NC3® must always be securely assembled in an upright posion throughout the enre
me that it is in use.
- The medin-NC3® must not be covered while in use, and none of the openings or venlaon slits
must be blocked.
- The overpressure valve should not be blocked during the enre duraon of operaon of the medin-
NC3®.
- A damaged medin-NC3® may not be used.
- Do not load the trolley with more than the permissible weight. The maximum permissible weight
(safe working load) is 40 kg (88 lb).
- The respiratory air humidier should be placed lower than the paent.
Aenon:
- Lock the wheel brakes of the trolley before you begin the installaon.
- Release the brakes before you move the trolley in order to avoid pping.
- Do not lean against the trolley.
- Ensure that all accessories are correctly assembled on the trolley.
- The trolley may p if the oor has an incline of more than 5°.
The medin-NC3® must always be securely assembled before the device is started up. To do this, it is placed on the
baseplate of the trolley (ancillary equipment REF 5008) such that the feet lie in the intended grooves and then it
is xed in place manually using the knurled screw (Figure 3-1– b).
The medin-NC3® can now be transported on this trolley provided that the oxygen supply is also aached to the
trolley. However, if the medin-NC3® becomes damaged during this transport or due to rough handling, its funcon
must be checked by a service technician. It is not allowed to be used unl then!
