Medin NC3 - Technical Data

Dimensions (L x W x H) 34 x 25 x 25 cm
Weight 6.25 kg
Gas feed system Computer-controlled electronic gas mixer with integrated oxygen
sensor and integrated blower; ow-controlled
Seng range: 0 L/min to 17.5 L/min (in 0.1 L/min increments)
Control range: 2 L/min to 17.5 L/min
Accuracy: ± 1 L/min (2 to 10 L/min)
± 2 L/min (10 to 17.5 L/min)
Gas feed Air: Ambient air, internal blower
Oxygen: 300 to 700 kPa (= 3.0 to 7.0 bar)
Gas connecon Connector standard: DISS or NIST (as preferred)
Paent ow outlet Dimensions M22 (OD) or F15 (ID)
CPAP pressure meter connecon Luer-type – 4.3 mm ID
Power supply 1x internal baery, 1x external baery (oponal), 14.4 V DC, run
me approx. 2 hours per baery, rechargeable
External power supply 100 to 240 V AC / 50 to 60 Hz
Display 7.0“ – color, 800 x 480 pixel
Data Paent pressure (diagram and measurement)
Trend: CPAP, FiO
2
, RR, push frequency, ow, rate, I:E (up to 28 days)
CPAP Measurement range 0 to 20 mbar (in 0.1 mbar increments)
Vericaon: Redundant measurement by two sensors
Accuracy: ± 1.3 mbar
Push (inspiraon support) Seng range
Addional ow during the inspiraon push with up to 70% of the
basic ow:
Min: 0 L/min
Max: 17.5 L/min (basic ow + push ow)
Duraon 200 ms to 3 seconds
Manual and automac triggering of pushes
Accuracy: Analogous to the accuracy of the basic ow, aer the
adjustment me has expired
Leak-Assist Leakage compensaon (± 5 L/min to maintain the target pressure)
in all CPAP modes (not in High Flow mode)
RR (respiraon rate) Oponal display of the measured respiratory rate, no display up to
120 breaths per minute, in CPAP and Apnea CPAP mode
Apnea me 2 to 30 s (in 1 s increments)
T
insp.
0.2 to 3.0 s (in 0.1 s increments)
Triggering Pressure trigger, based on the CPAP pressure sensivity, ±0.2 to
±1.0 mbar (in 0.1 mbar increments)
medin Medical Innovaons GmbH
Adam-Geisler-Str. 1
82140 Olching, Germany
+49 8142 448 460
info@medin-medical.com
www.medin-medical.com
IFU_medin-NC3 EN
Rev 05 Status as of 28.04.2021
9 of 68
Warning:
The medin-NC3® may not be modied without permission from the manufacturer and subsequent appropriate
examinaons and tesng to guarantee connued safe use.
2.6.2. Technical data
Basis of measurement: DIN 1343 at 0°C, 1013.25 mbar and 0% air humidity (0/1013)
