megapixel HELIOS - Output Port Capacity

HELIOS LED Processing Platform - USER GUIDE 111
HELIOS Processor - Supported SDI Input Formats
NOTES:
• The pixel format must be YCbCr 4:2:2
• All video signals must be Level A with the exception of 1080p 50/60 Hz can be Level B.
• Inputs can be combined using 2SI or square division. Square division is only supported across separate physical
inputs (not within a single 12G link).
• HELIOS does not support interlaced or progressive segmented frame (PsF) signals.
HELIOS Processor - Output Port Capacity (Pixels)
Bit Depth 10 10 10 12 12 12
Connection Switch to Tiles Switch to Tiles HELIOS to Switch Switch to Tiles Switch to Tiles HELIOS to Switch
Ethernet Speed (Gbps) 1 2.5 10 1 2.5 10
Video FPS
24 1,275,000 3,187,500 12,750,000 1,062,500 2,656,250 10,625,000
25 1,225,000 3,062,500 12,250,000 1,020,000 2,550,000 10,200,000
30 1,020,000 2,550,000 10,200,000 850,000 2,125,000 8,500,000
48 635,000 1,587,500 6,350,000 531,000 1,328,125 5,312,500
50 610,000 1,525,000 6,100,000 510,000 1,275,000 5,100,000
60 510,000 1,275,000 5,100,000 425,000 1,062,000 4,250,000
120 240,000 600,000 2,400,000 200,000 500,000 2,000,000
144 195,000 487,500 1,950,000 160,000 400,000 1,600,000
240 100,000 250,000 1,000,000 90,000 225,000 900,000
Supported Resolutions for each SDI Input
1280 x 720
1920 x 1080
2048 x 1080
3840 x 2160
4096 x 2160
Supported Frame Rates
23.98 / 24
24.97 / 25
29.97 / 30
49.95 / 50
59.94 / 60
