HELIOS LED Processing Platform - USER GUIDE
Fiber Out / Data to Tiles
Network Ports
The HELIOS Processor is running a Linux build based on Alpine Linux. The following network ports and services are used
by the system:
Network Ports Notes
443 (TCP) Main Web UI and Public API (HTTPS)
80 (TCP) Main Web UI and Public API (HTTP)
1900 (TCP+UDP) Service Discovery (SSDP)
5353 (UDP) Service Discovery (mDNS)
5568 (UDP) Public API / Control (sACN)
56004 (TCP+UDP) HELIOS stacking
ICMP Network ping, etc.
720p
(1280 x 720)
1080p
(1920 x 1080)
UHD
(3840 x 2160)
DCI 4K
(4096 x 2160)
5K
(5120 x 2880)
6K
(6016 x 3384)
8K
(7680 x 4320)
DCI 8K
(8192 x 4320)
120 Hz
444 12-bit
1 x 10Gb 2 x 10Gb 5 x 10Gb 6 x 10Gb 8 x 10Gb No No No
444 10-Bit
1 x 10Gb 2 x 10Gb 4 x 10Gb 5 x 10Gb 8 x 10Gb 8 x 10Gb No No
60 Hz
444 12-bit
1 x 10Gb 1 x 10Gb 3 x 10Gb 3 x 10Gb 5 x 10Gb 5 x 10Gb No No
444 10-bit
1 x 10Gb 1 x 10Gb 3 x 10Gb 3 x 10Gb 4 x 10Gb 5 x 10Gb 8 x 10Gb 8 x 10Gb
30 Hz
444 12-bit
1 x 10Gb 1 x 10Gb 2 x 10Gb 2 x 10Gb 3 x 10Gb 3 x 10Gb 5 x 10Gb 6 x 10Gb
444 10-bit
1 x 10Gb 1 x 10Gb 2 x 10Gb 2 x 10Gb 2 x 10Gb 3 x 10Gb 5 x 10Gb 5 x 10Gb
