HELIOS LED Processing Platform - USER GUIDE
4
3 - SFP+ Inputs - Four (4) SFP+ slots provide copper SDI inputs. Each input requires a Megapixel 12G SFP+ and supports
formats up to 12G SDI. See the Input Capability Matrix in Appendix G for details. Indicators on each SFP+ slot show link
status.
4 - SFP+ Outputs - HELIOS Standard units support up to eight Megapixel 10G ber SFP+ outputs for data transmission to
the display. Likewise, HELIOS Junior units support up to eight Megapixel 1G copper SFP outputs. Indicators on each SFP+
slot show link status.
5 - External Sync - The BNC connector to the right of the ber outputs allows the HELIOS Processor to receive genlock
timing signals. An external sync is required when using multiple processors for data redundancy.
Indicator Color Meaning
Green
Link to switch
Blue
Connected to tiles
Indicator Color Meaning
Green
Receiving a carrier signal
Blue
Valid frame detected
