16
(4) Enclosure E: 4T18.5/22 kW
Fig. 1-5 Enclosure E
(5) Enclosure F: 4T30/37kW
Fig. 1-6 Enclosure F
Table 1-3 Outline, mounting dimensions and gross weight
Enclosure
model
Drive model
A (mm)
B1 (mm)
B2 (mm)
H (mm)
W (mm)
D
(mm)
Mounting
hole
diameter
(mm)
Gross
weight±
0.5 (kg)
