Megmeet MV820 - P21: Motor 2 Encoder Parameters

261
P20.22
Synchronous motor axis-Q
inductance
0.01 to 655.35 mH (drive power
≤
55
kW)
0.001 to 65.535 mH (drive power > 55
kW)
Model dependent
P20.23
Synchronous motor back
EMF
0.0 to 6553.5 V/krpm
Model dependent
P20.24 to P20.26
Reserved
P20.27
Motor auto-tuning
0 to 2
0
P20.28
Motor overload protection
factor
0.0 to 300.0%
100.0%
P20.29
Reserved
For the parameter description, refer to “7.4 P03: Motor 1 parameters”.
7.19 P21: Motor 2 encoder parameters
P21.00
Encoder PPR
1 to 65535
1024
P21.01
Encoder type
0
0
0: ABZ incremental encoder
P21.02
A/B phase sequence of ABZ incremental
encoder
0 to 1
0
0: Forward
1: Reverse
Note: The phase sequence will be automatically identified after rotation auto-tuning.
P21.03
Speed feedback PG wire breakage detection
time
0.0 to 10.0 s
0.0 s
Used to set the detection time for PG wire breakage. If it is set to 0.0, no detection will be done.
P21.04
PG card voltage class selection
0 to 1
0
0: 5 V
1: 12 V
P21.05 to P21.30
Reserved
For the parameter description, refer to “7.5 P04: Motor 1 encoder parameters”.
