18
Fig. 1-7 Appearance and mounting dimensions of operating panel
(1) A removable LED keypad (with a shuttle button) is the standard configuration for the whole MV820 series, which
supports external use. If you want to add a remote LCD keypad, refer to 2.2.8.
(2) An RJ45 port is reserved for an external keypad.
