Megmeet MV820 - Page 39

39
76
203,5
90
105105
6-M4
开孔尺寸
安装整机
安装支架
变频器
固定板
安装支架
Fig. 2-17 MV810-EMBB embedded mounting bracket kit
68
121
114
7
134
269
104
6
铆装螺母6-M4
左安装支架
自攻螺钉
右安装支架
M4组合螺钉
变频器
M4组合螺钉
变频器组件
穿墙安装底板
M4组合螺钉
M4组合螺钉
Fig. 2-18 MV810-EMBC embedded mounting bracket kit
铆接6-M4螺母
114
156
145
16,5
164
9
114
300
325,5
自攻螺钉
右安装支架
M4组合螺钉
M4组合螺钉
M4组合螺钉
M4组合螺钉
变频器安装组件
穿墙安装底板
左安装支架
变频器
M4组合螺钉
Fig. 2-19 MV810-EMBD embedded mounting bracket kit
Mounting
bracket
Left bracket
Drive
Mount the bracket
Mount the drive
Mounting
plate
Hole dimensions
Self-tapping
screw
Right bracket
Drive
M4 combination screw
M4 combination screw
M4 combination
screw
M4 combination
screw
Drive component
Through-wall mounting plate
Rivet nut 6-M4
Left bracket
Self-tapping
screw
Right bracket
Drive component
M4 combination screw
Through-wall mounting plate
M4 combination screw
M4 combination
screw
M4 combination
screw
M4
screw
combination
Rivet nut 6-M4
Drive
