Fig. 3-3 Guide rail installation
If two or more drives are installed closely up and down, for better heat dissipation, it is recommended to use a baffle
plate to redirect the flow, preventing the lower drive from affecting the upper drive, as shown in Fig. 3-4.
Fig. 3-4 Installation of over two drives
