14 Technical data
67
14 Technical data
Device type MELAquick 12+ MELAquick 12+ p
Device dimensions (W x H x D): 19.5 x 43 x 47 cm 20.5 x 43 x 46 cm
Empty weight 23 kg 24 kg
Operating weight approx. 25 kg
Sterilization chamber
Diameter 9 cm
Depth 20 cm
Volume 1.35 l
Electrical connection
Power supply 220-240 V, 50/60 Hz 220-240 V, 50 Hz
Max. voltage range 207-253 V
Electrical power 2050 W
Building fuse 16 A Type B, RCD 30 mA
Overvoltage category Transient overvoltages up to the values of overvoltage category II
Air pollution degree (in accordance with
EN 61010-1)
Category 2
Length of the power cable 2.5 m
Ambient conditions
Installation location interior of a building
Noise emission 66 dB(A) 69 dB(A)
Heat emission (with max. load) approx. 0.48 kW (1.74 MJ/h)
Ambient temperature 5-40 °C (ideal range 16-26 °C)
Relative humidity max. 80 % at temperatures of up to 31 °C, max. 50 % at 40 °C (decreasing
in linear fashion in-between)
Protection class (in accordance with
IEC 60529)
IP20
Max. altitude 2000 m
Feed water connection
Water quality demineralised and/or distilled water according to EN 13060, Appendix C
(with central demineralisation system max. conductivity 5 μS/cm)
Recommended flow pressure 0.5 bar at 0.8 l/min
Min. water pressure (static) 0.5 bar
Max. water pressure (static) 10 bar
Max. water consumption approx. 280 ml
Volume feed water container 5 l
Number cycles feed water container approx. 20
Feed water volume initial commissioning min. 1.5-2 l
Max. temperature 40 °C
Wastewater connection
Max. temperature approx. 100 °C (direct in wastewater container)
