MELAG MELAquick 12+ - Mains Electrical Connection; Water Connection and Requirements

5 Installation requirements
19
Mains connection
WARNING
Improper installation may lead to a short-circuit, fire, water damage or electrical shock.
This could result in serious injury.
n Only have the device set up, installed and commissioned by people authorised by MELAG.
Comply with the following for safe handling:
n Never damage or alter the power plug or cable.
n Never bend or twist the power cable.
n Never remove the plug by pulling on the power cable. Always take a grip on the plug.
n Never place any heavy objects on the power cable.
n Never run the power cable over areas in which it could become trapped (e.g. doors or windows).
n Never lead the cable along a source of heat.
n Never use any nails, paper fasteners or similar objects to fix the cable.
n Should the power plug or cable suffer damage, switch off the device. The power cable or plug should only be
replaced by authorised technicians.
PLEASE NOTE
The IEC plug on the steam sterilizer or the mains socket must be freely accessible after installation so
that the steam sterilizer can be taken from the electricity supply at any time.
On-site requirements
Property MELAquick 12+ MELAquick 12+ p
Power supply 220-240 V, 50/60 Hz*
)
220-240 V, 50 Hz*
)
Building fuse A separate circuit with 16 A Type B, RCD 30 mA (to guarantee continued practice
operation during steam sterilizer malfunction)
Other additional socket for the MELAprint42/44 log printer etc.
Length of the power cable 2.5 m
*
)
Max. voltage range 207-253 V
Water connection
The steam sterilizer works in the gentle yet effective one-steam way water system. This means that the device uses
fresh purified }feed water for every sterilization run for the steam generation.
On-site requirements
Feed water Wastewater
Connection in the practice External feed water container
to a water treatment unit, e.g.
MELAdem 40/ 47
Emptying into the external wastewater
container
Installation height -- Min. 30 cm under the steam sterilizer
Max. temperature 40 °C approx. 100 °C (direct in wastewater
container)
Recommended flow
pressure
0.5 bar at 0.8 l/min (average at least 0.025 l/
min [= 1.5 l/h])
--
Min. water pressure (static) 0.5 bar --
Max. water pressure
(static)
10 bar --
