SECTION 6
MAINTENANCE
164
Lubricate the Worm Gear on the Lifting Arm Motor
1. Apply lubricant (Super Lube 21030 or equivalent)
to the Worm Gear.
Lubricate Service Station Sled Rails and Service Station Side Rail Tracks
1. Eject the Service Station.
2. Apply lubricant (Super Lube 21030 or equivalent) along the full length of the side rails of the
Service Station Sled. These edges ride in the Service Station Side Rail Tracks shown in next step.
3. Apply lubricant (Super Lube 21030 or equivalent). along full length the Service Station Side Rail
Tracks, as shown.
(1 on each side).
