Mercury 45 Service Manual

CYLINDER BLOCK/CRANKCASE
Page 4B-40 90-828631R3 MARCH 1999
6. Reinstall stator with three bolts.
53745
c
a
b
a-Stator
b-Mounting Bolts (3) Apply Loctite 222 to Threads
c-Sta-Strap
Stator Bolt Torque
75 lb-in. (8.5 Nm)
7. Place flywheel key into slot.
8. Install flywheel.
9. Apply oil to threads on crankshaft and tighten nut to the specified torque.
a
c
b
d
a-Flywheel Key
b-Washer
c-Nut
d-Apply Oil to Threads
Flywheel Nut Torque
116 lb-ft (157 Nm)

Mercury 45 Specifications

General

Horsepower	45 HP
Cylinders	3
Starting	Electric
Full Throttle RPM Range	5000-6000 RPM
Steering	Remote
Exhaust	Through Prop
Shaft Length	20 in
