Mercury 45 Service Manual

NON-BIGFOOT GEAR HOUSING
Page 6A-2190-828631R3 MARCH 1999
13. Insert spring hook (91-825200A1) or bearing cup puller (91-859749) through gear case
and position inside of pinion bearing race. Insert driver (91-13779) into spring hook or
driver (91-44385) into bearing cup puller through drive shaft cavity and drive out race.
52844
91-825200A1
b
a
57829
91-13779
or
c
d
91-859749
91-44385
a-Spring Hook (91-825200A1)
b-Driver (91-13779)
c-Bearing Cup Puller (91-859749)
d-Driver (91-44385)
14. Remove forward bearing race with puller (91-27780).
53838
91-27780
b
a
a-Bearing Race
b-Puller (91-27780)

Mercury 45 Specifications

General

Horsepower	45 HP
Cylinders	3
Starting	Electric
Full Throttle RPM Range	5000-6000 RPM
Steering	Remote
Exhaust	Through Prop
Shaft Length	20 in
