Mercury 90-863160

BRAVO TWO GEAR HOUSING
SERVICE MANUAL NUMBER 28
90-863160 MAY 2000 Page 3C-9
4. Remove bearing carrier retainer nut using bearing carrier retainer wrench
(P/N 91-17257).
22112
a
a-Bearing Carrier Retainer Wrench
5. Remove bearing carrier using slide hammer puller.
19842
a
b
a-Slide Hammer Puller, 91-34569A1
b-Puller Jaws, 91-46086A1
6. Remove propeller shaft assembly.
24211
a
a-Lift Propeller Shaft From Gear Housing
