POWER STEERING SERVICE MANUAL NUMBER 28

Page 6A-6 90-863160 MAY 2000

Power Steering System

75237

NEUTRAL

HIGH PRESSURE

1150-1250 PSI

LOW PRESSURE

70-125 PSI

PISTON

CONTROL VALVE

RELIEF VALVE

PUMP

PUMP HOUSING

OIL COOLER

(VIEWING FROM INSIDE OF BOAT LOOKING AT TRANSOM)
