Mercury 90-863160

POWER STEERING
SERVICE MANUAL NUMBER 28
90-863160 MAY 2000 Page 6A-19
Power Steering Pump
Removal
1. Loosen the adjusting stud and remove the serpentine belt from the power steering
pulley.
75483
a
a-Adjusting Nut
NOTE: Use a suitable container catch ant power steering fluid when removing the power
steering hoses.
2. Remove the high pressure hose and return hose from the power steering pump.
75228
a
b
Power Steering Pump Typical Location
a-Return Hose
b-High Pressure Hose
