Mercury 90-863160

BRAVO TWO GEAR HOUSING SERVICE MANUAL NUMBER 28
Page 3C-24 90-863160 MAY 2000
Propeller Shaft Bearing Removal
1. Press bearing from shaft using universal puller plate.
22110
a
b
c
a-Propeller Shaft
b-Universal Puller Plate
c-Tapered Roller Bearing
Propeller Shaft Bearing Installation
1. Apply Gear Lube to inside diameter of new bearing. Install bearing to shaft using
universal puller plate and a suitable mandrel (old bearing race) which supports bearing
on inner race. Press into place.
22110
a
c
d
b
a-Propeller Shaft
b-Tapered Roller Bearing
c-Suitable Mandrel
d-Universal Puller Plate
