Mercury 90-863160

BRAVO TWO GEAR HOUSING
SERVICE MANUAL NUMBER 28
90-863160 MAY 2000 Page 3C-13
14. Unless you plan to remove the pinion bearing, remove needle bearings from drive shaft
needle bearing race. (See Pinion Bearing Removal)
22083
a
b
a-Needle Bearings
b-Drive Shaft Needle Bearing Race
15. Remove water passage O-ring and oil passage quad ring.
22222
a
b
a-Remote Water Passage O-Ring
b-Oil Passage Quad Ring
