BRAVO THREE GEAR HOUSING
SERVICE MANUAL NUMBER 28
90-863160 MAY 2000 Page 3D-7
1-Retainer
2-Coupler
3-O-ring
4-Spacer
5-Shim(s)
6-Tab Washer
7-Bearing Cup
8-Bearing Cup
9-Shim(s)
10 - Drive Shaft
11 - Tapered Roller Bearing (Larger Dia.)
12 - Tapered Roller Bearing (Smaller Dia.)
13 - O-ring
14 - Seal
15 - Locknut
16 - Flat Washer
17 - Oil Passage Quad Ring
18 - Screw
19 - Anodic Plate
20 - Needle Bearings
21 - Bearing Race
22 - Pinion (Drive) Gear
23 - Washer
24 - Pinion Bolt
25 - Shim(s)
26 - Bearing Cup
27 - Tapered Bearing
28 - Front Gear
29 - Inner Propeller Shaft
30 - Thrust Bearing
31 - Thrust Race
32 - Shim (Prop Shaft End-Play)
33 - Snap Ring
34 - Rear Gear
35 - Tapered Bearing
36 - Outer Propeller Shaft
37 - Bearing
38 - Inner Propeller Shaft Seal
39 - Shim(s)
40 - Bearing Cup
41 - Bearing Retainer (Nut)
42 - O-ring
43 - Bearing Carrier
44 - Bearing
45 - Outer Propeller Shaft Seal
46 - Front Propeller Thrust Washer
47 - Front Propeller Locknut
48 - Rear Propeller Thrust Washer
49 - Rear Propeller Locknut
A
3M Brand Adhesive
B
Quicksilver Needle Bearing Assembly Lubricant
C
Loctite 271
D
Quicksilver High Performance Gear Lube (Use on all bearing surfaces)
E
Quicksilver Special Lubricant 101
F
Quicksilver 2-4-C Marine Lubricant with Teflon
H
Perfect Seal
