CORROSION PROTECTION - ALL MODELS
SERVICE MANUAL NUMBER 28
90-863160 MAY 2000 Page 7A-7
CAUTION
To be effective, new anodic plate MUST make good electrical contact with gear
housing.
3. Scrape anodic plate mounting surface on gear housing down to bare metal.
4. Install anodic plate. Torque screw to 30 lb-ft (41 Nm).
a
b
c
d
e
76800
a-Anodic Plate
b-Rubber Plug (Removed)
c-1/2 in. Socket
d-Extension
e-Screw
5. Reinstall plug in driveshaft housing.
22093
a
a-Rubber Plug
