REMOVAL, INSTALLATION AND ADJUSTMENTS SERVICE MANUAL NUMBER 28
Page 2A-10 90-863160 MAY 2000
6. Remove the continuity wire from the steering lever.
22028
a
c
b
a-Steering Lever
b-Screw
c-Continuity Wire
7. Disconnect the speedometer hoses.
70015
a
a-Speedometer Fitting
8. Remove seawater intake hose.
d
a
b
c
76636
a-Seawater Intake Hose
b-Seawater Pickup Outlet
c-Bolts and Star Washers
d-Gear Lube Monitor Hose
9. Remove seawater pickup outlet.
10. Remove gear lube monitor hose.
