Chapter 4—Front Panel Operation
45
Viewing Configuration Data The circuit monitor provides a special protected viewing mode that lets you
In Protected Mode view, but not change, configuration data.
To view configuration data, complete the following steps:
1. Press the MODE button until the red LED next to [Setup] is lit.
The circuit monitor displays “ConFig”.
2. Press the PHASE [Enter] button.
The circuit monitor displays the password prompt “P - - - -.”
3. Enter 9999 for the password.
To enter 9999, use the SELECT METER [Value] buttons to decrease the
displayed value until it reaches 9999. Then press the PHASE [Enter]
button.
The circuit monitor enters the protected viewing mode and scrolls
through the following device information:
• d=2350 (the number after “d=” represents the device model number)
• s=0345 (the numbers following “s=” represent the last four digits of
the device serial number)
• r=1516 (the first two digits after “r=” represent the reset code
revision and the last two digits represent the circuit monitor
firmware revision level
• 1=001 (the digits following “1=” represent the circuit monitor
firmware sub-revision level, as in firmware version 17.002)
After this scrolling sequence, the display shows the present CT ratio.
4. Press the PHASE [Enter] button to move from one configuration item to
the next.
5. To exit the protected viewing mode, press the MODE button.
The circuit monitor returns to METERS mode.
