Appendix A—Circuit Monitor Dimensions
71
APPENDIX A—CIRCUIT MONITOR DIMENSIONS
9.14
232
12.02
305
10.35
263
.83
21
3.71
94
3.15
80
.56
14
Rear View Side View
7.35
187
.89
23
Top View
Protective covers
shown installed.
Inches
Millimeters
Dimensions
Figure A-1: Circuit monitor dimensions
