Merlin Gerin PowerLogic 2000 Series User Manual

Chapter 4—Front Panel Operation
57
Figure 4-3: Flowchart for performing resets using the Resets option
YES
NO
Do you want to
select another
reset option?
Press the PHASE
(Enter) key to select
the “rESETS” option.
P---- is displayed.
Press the
▼ SELECT METER
key until “rESETS”
is displayed.
Press MODE key
until [Setup] LED
is lit.
Start
Press the SELECT
METER keys until your
password is displayed .
Then press t
h e
PHASE (Enter) key.
No is displayed.
Press the PHASE
(Enter) key until the
LED next to the value
to be reset is lit.
Press the ▲ SELECT
METER (Value) key
to change from
No to Yes .
Press the MODE key
once.
Circuit Monitor
displays
No .
Execute the
selected
resets?
Press the ▲ SELECT
METER (Value) key
to select Yes
Press PHASE (Enter)
key
Circuit Monitor
performs resets
YES
NO
Press the PHASE
(Enter) key
Circuit Monitor returns
to METERS mode.
