Chapter 4—Front Panel Operation
55
Resetting Demand, The following values can be reset from the circuit monitor front
Energy, and Min./Max. Values panel: Demand Ammeter (A), Demand Power (W), Demand Power (VA),
Watthour Meter, Varhour Meter, and Minimums and Maximums.
Demand Power (W) and Demand Power (VA) are reset together; you cannot
reset one without resetting the other. Likewise, the Watthour Meter and
Varhour Meter are reset together.
Note: You can also reset energy, demand, and min/max values using the Resets
option. The Resets option lets you perform resets but not change configuration
values. See Performing Resets Using the Resets Option on
the next page for more information.
To reset data, complete the following steps:
1. Press the MODE button until the red LED next to [Setup] is lit.
The circuit monitor displays “ConFig.”
2. Press the PHASE [Enter] button to select the Configuration option.
The circuit monitor displays the password prompt “P - - - -.”
3. Enter the password.
To enter the password, use the SELECT METER [Value] buttons to
increase or decrease the displayed value until it reaches the password
value. Then press the PHASE [Enter] button.
4. Press the PHASE [Enter] button until the red LED next to
the desired reset item flashes.
Remember, if you choose Demand Power (W), the LED for Demand
Power (VA) also lights, and vice versa. Likewise, if you choose Watthour
Meter, the LED for Varhour Meter also lights, and vice versa.
5. Press the up arrow SELECT METER [Value] button to change the circuit
monitor display from No to Yes.
6. Repeat steps 4 and 5 until you’ve said Yes to all items to be reset.
7. Press the MODE button once.
The red LED next to [Accept] flashes. The red LEDs next to the selected
reset items glow steadily.
8. To cancel the reset(s), press the PHASE [Enter] button once.
The circuit monitor display flashes and the circuit monitor returns to
METERS mode.
9. To perform the reset(s), press the SELECT METER [Value] button once to
change from No to Yes. Then, press the PHASE [Enter] button.
The circuit monitor performs the resets and returns to METERS mode.
