Chapter 4—Front Panel Operation
51
Setting the Watthour/ The allowable range for the watthours-per-pulse output is 0 to 3,276.7 kWH.
Pulse Output The watthours per pulse can be set in one-tenth kWH increments, generating
a pulse as often as every 0.1 kWH (not to exceed 10 pulses per second), or as
seldom as every 3276.0 kWH. Setting the watthours per pulse to 0 disables
the pulse. The factory default is 0.
Note: The circuit monitor must be equipped with an input/output module to use this
feature. For a more detailed description of the watthour pulse output feature, see
Solid-State KYZ Pulse Output in the Circuit Monitor Reference Manual.
To change the Watthour/Pulse output, complete the following steps:
1. Press the MODE button until the red LED next to [Setup] is lit.
The circuit monitor displays “ConFig.”
2. Press the PHASE [Enter] button to select the Configuration option.
The circuit monitor displays the password prompt “P - - - -.”
3. Enter the password.
To enter the password, use the SELECT METER [Value] buttons to
increase or decrease the displayed value until it reaches the password
value. Then press the PHASE [Enter] button.
4. Press the PHASE [Enter] button until the red LED next to [WH/Pulse]
flashes.
5. Press the SELECT METER [Value] buttons until the desired
kilowatthours per pulse value is displayed.
6. Press the MODE button once.
The red LED next to [Accept] flashes. The red LED next to [WH/Pulse]
glows steadily.
7. To reject the new pulse interval, press the PHASE [Enter] button once.
The circuit monitor returns to METERS mode.
8. To accept the new pulse interval, press the SELECT METER [Value]
button to change from No to Yes. Then, press the PHASE [Enter] button.
The circuit monitor restarts.
