Chapter 4—Front Panel Operation
61
You must assign these actions to alarm conditions using POWERLOGIC
software.
Depending on the chosen priority level, the circuit monitor also performs
the actions described below.
P0—No priority. On the occurrence of a P0 alarm, the circuit monitor
does the following:
Performs any assigned actions
P1—Highest priority level. On the occurrence of a P1 alarm, the circuit
monitor does the following:
Puts the alarm number in the list of active alarms, accessible from the
front panel (see Viewing Active Alarms in the Circuit Monitor
Reference Manual for instructions on viewing active alarms)
Records the occurrence in the circuit monitor’s event log file
Enters the alarm number in the P1 log, accessible from the front panel
(see Viewing the Priority 1 Log in the Circuit Monitor Reference Manual
for a instructions on viewing the P1 log)
Performs any assigned actions
P2—Middle priority level. On the occurrence of a P2 alarm, the circuit
monitor does the following:
Puts the alarm number in the list of active alarms, accessible from the
front panel (see Viewing Active Alarms in the Circuit Monitor
Reference Manual for instructions on viewing active alarms)
Records the alarm occurrence in the circuit monitor’s event log file
Performs any assigned actions
P3—Lowest priority level. On the occurrence of a P3 alarm, the circuit
monitor does the following:
Puts the alarm number in the list of active alarms, accessible from the
front panel (see Viewing Active Alarms in the Circuit Monitor
Reference Manual for instructions on viewing active alarms)
Records the alarm occurrence in the circuit monitor’s event log file
Performs any assigned actions
8. Press the PHASE [Enter] button to select the priority level.
The display alternates between “PU SP” (an abbreviation for pickup
setpoint) and the setpoint value.
9. Use the SELECT METER [Value] buttons to increase or decrease the
displayed value until you reach the desired pickup setpoint.
See Setpoint-Driven Alarms in the Circuit Monitor Reference Manual for a
description of pickup and dropout setpoint and time delays.
If you are configuring an alarm condition that does not require some or
all of the pickup and dropout setpoints and delays, for example status
