Metor 6M PAGE 15
Installation and Operating Manual
92102916 REV 5 5. INSTALLATION SITE
NOTICE
The above distances are recommendations. The final installation distances
are determined by the installation site.
NOTICE
Always install the equipment so that the receiver panel (MRXS) is further
away from the source of interference.
A
B
C
> 0.2 m / 8 in.
> 0.5-2m/20-79in.
> 0.5 - 4 m / 20 - 157 in.
A: Distance from static metal
B: No moving metal objects
C: No electrical interference sources
Recommended minimum distances
from interference sources
