3.13 Connecting MSB devices
￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭
34
￭￭￭￭￭￭￭￭
855 Robotic Titrosampler
CAUTION
Exit the control software before you plug in MSB devices. When it is
switched on, the control instrument automatically recognizes which
device is connected to which MSB connector. The operating unit or the
control software enters the connected MSB devices into the system
configuration (device manager).
MSB connections can be extended with the 6.2151.010 cable. The maxi-
mum connection length permitted is 15 m.
3.13.1 Connecting a dosing device
Three dosing devices can be connected to the instrument.
The types of dosing devices that are supported are:
￭ 800 Dosino
￭ 700 Dosino
￭ 805 Dosimat
￭ 685 Dosimat plus
WARNING
If a Dosino is connected to the 855 Robotic Titrosampler, then the con-
nection cable must be equipped with a T.2400.102 ferrite core. The fer-
rite core diminishes any interference voltages and thus ensures compli-
ance with the strict EMC standards in accordance with the applicable
technical standards, see EU declaration of conformity of the instrument.
Proceed as follows:
1
Mounting the ferrite core
￭ Fasten a T.2400.102 ferrite core to the Dosino connection cable
close to the plug.
2
Connecting a dosing device
￭ Exit the control software.
￭ Connect the connection cable of the dosing device to one of the
sockets marked with MSB on the rear of the control device.
￭ Start the control software.
