3 Installation
855 Robotic Titrosampler
￭￭￭￭￭￭￭￭
27
2
Fixing the rinsing tubings
￭ Place the rinsing tubings into the guide chain (see chapter 3.9,
page 27).
3.9 Placing tubing and cables in the guide chain
Tubing and cables can be placed in the guide chain.
The guide chain contains a firmly installed clip on each chain link.
CAUTION
When mounting tubing and cables, make sure that there is no traction
on the drives while moving the lift or swinging the robotic arm. Traction
on the drive can overload and damage the drive.
If a robotic arm is used, we recommend placing the tubing and cables
only above the third chain link in the guide chain to prevent traction on
the drives.
Do not or only partially place rigid tubings, as for example aspiration
tubings made of PTFE, into the guide chain.
NOTICE
Make sure that tubing and cables do not kink.
Inserting and removing the tubing and cables requires no tools.
1
Placing tubing and cables
￭ Press one side of the clip downwards and place tubing or cables
in the guide chain.
