6 Appendix
855 Robotic Titrosampler
￭￭￭￭￭￭￭￭
51
6.5 Robotic arms
6.5.1 Robotic arms for titration
Table 3 Configuration data of the titration robotic arms
Type 6.1462.050 6.1462.060 6.1462.070 6.1462.260
Swing direction +/– + – +
Swing offset 0° –8° –8° –8°
Max. swing angle 84° 73° 73° 105°
Swing radius 110 mm 127 mm 127 mm 110 mm
6.1462.050 Robotic arm with titration head, left or right-swinging
For titration in 75 mL sample vessels and larger.
The arm can be equipped with two microelectrodes, one propeller stirrer
and three spray nozzles. Two buret tips with anti-diffusion valve and one
aspiration tip with connections for M6 tubing are already retracted into
the arm.
Material: PP
6.1462.060 Robotic arm with holder for a titration head, left-swinging
The arm can be modified to create the desired titration robotic arm by
means of the installation of a titration head 6.1458.xxx.
Material: PP
6.1462.070 Robotic arm with holder for a titration head, right-swinging
The arm can be modified to create the desired titration robotic arm by
means of the installation of a titration head 6.1458.xxx.
Material: PP
