6.5 Robotic arms
￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭
52
￭￭￭￭￭￭￭￭
855 Robotic Titrosampler
6.1462.260 Robotic arm with holder for a titration head, left-swinging, exter-
nal
The arm can be modified to create the desired titration robotic arm by
means of the installation of a titration head 6.1458.xxx. The cutout per-
mits movement to external positions near the rack, e.g. an external rinsing
station.
Material: PVC
Table 4 Configuration data of the robotic arms with beaker sensor
Type 6.1462.150 6.1462.160 6.1462.170
Swing direction +/– + –
Swing offset 0° –8° –8°
Max. swing angle 84° 73° 73°
Swing radius 110 mm 127 mm 127 mm
6.1462.150 Robotic arm with titration head and beaker sensor, left or right-
swinging
For titration in 75 mL sample vessels and larger.
The arm can be equipped with two microelectrodes, one propeller stirrer
and three spray nozzles. Two buret tips with anti-diffusion valve and one
aspiration tip with connections for M6 tubing are already retracted into
the arm.
Material: PP
6.1462.160 Robotic arm with holder for a titration head and beaker sensor,
left-swinging
The arm can be modified to create the desired titration robotic arm by
means of the installation of a titration head 6.1458.xxx.
Material: PP
