6 Appendix
855 Robotic Titrosampler
￭￭￭￭￭￭￭￭
53
6.1462.170 Robotic arm with holder for a titration head and beaker sensor,
right-swinging
The arm can be modified to create the desired titration robotic arm by
means of the installation of a titration head 6.1458.xxx.
Material: PP
6.5.2 Robotic arms for sample preparation
Table 5 Configuration data of the robotic arms for sample preparation
Type 6.1462.030 6.1462.040 6.1462.090 6.1462.240
Swing direction + – – –
Swing offset 8° 8° 8° –8.6°
Max. swing angle 117° 117° 117° 122°
Swing radius 112 mm 112 mm 112 mm 149.8 mm
6.1462.030 Robotic arm with transfer head, left-swinging
Robotic arm for fully automated pipetting or dilution of liquid samples
with Sample Processor Systems.
Material: PP
6.1462.040 Robotic arm with transfer head, right-swinging
Robotic arm for fully automated pipetting or dilution of liquid samples
with Sample Processor Systems.
Material: PP
6.1462.090 Robotic arm with Luer lock adapter, right-swinging
For the connection of hollow needles with Luer lock connection. Suitable
for the transfer of samples from sealed vials with septum seal.
Material: PP
6.1462.240 Robotic arm with transfer head, bent, right-swinging
The transfer head can, when equipped with 6.1808.220 adapter, be used
as a holder for various tools with Luer connection on multirow racks.
