6.3 Remote interface
￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭
48
￭￭￭￭￭￭￭￭
855 Robotic Titrosampler
Figure 32 Spray nozzles - Mode of operation
The height of the nozzles can be adjusted in the titration head in order to
reach an optimal rinsing effect.
6.3 Remote interface
The 6.2148.010 Remote Box allows devices to be controlled which cannot
be connected directly to the MSB interface of the Titrosampler.
Figure 33
Connectors of the Remote Box
1
Cables
For connecting to an MSB connector of the
Titrosampler.
2
MSB connector
Metrohm Serial Bus. For connecting external
dosing devices or stirrers.
3
Remote connector
For connecting instruments with a remote
interface.
