Metrohm 883 Basic IC plus - Rear View of the Instrument

￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭
2 Overview of the instrument
883 Basic IC plus
￭￭￭￭￭￭￭￭
7
2.2 Rear
Figure 2 883 Basic IC plus rear
1
On/off switch
2
Power socket
3
PC connection socket
4
Detector connection socket
5
Transport locking screws
6
Knurled screws
For fastening the removable back panel.
7
Back panel
Removable. Access to the detector chamber.
8
Capillary feed-throughs
