3 Installation
883 Basic IC plus
￭￭￭￭￭￭￭￭
17
3.6 Installations on the rear of the instrument
3.6.1 Positioning and connecting the detector
1
1
1
2
3
4
5
5
Figure 4 Positioning the detector
1
Knurled screws
For fastening the removable back panel.
2
Back panel
Removable. Access to the detector chamber.
