3 Installation
883 Basic IC plus
￭￭￭￭￭￭￭￭
21
Installing the drainage tubing
Proceed as follows to replace the drainage tubing:
1
Connect the drainage tubing (5-2) to the drainage tubing connection
(5-1) and shorten it to the required length.
2
Connect the drainage tubing (5-4) to the drainage tubing connection
(5-3) and shorten it to the required length.
3
Connect the drainage tubing (5-2) and the drainage tubing (5-4) to
each other using the Y connector (5-5).
4
Connect the drainage tubing (5-6) to the Y connector (5-5). Guide
the other end into a waste container.
3.7 Capillary and cable feed-throughs
Several openings have been integrated for feeding through capillaries and
cables. These can be found at the door (6-4), and at the rear panel (2-8).
