3 Installation
883 Basic IC plus
￭￭￭￭￭￭￭￭
33
NOTICE
The adapter's sealing surface is located approx. 4 mm deep inside
the suppressor drive if the adapter is inserted correctly.
If this is not the case, then the adapter has to be moved into the
correct position from below by means of a pointed object (e.g. a
screwdriver).
3
Inserting the connecting piece
￭ Clean the sealing surface of the connecting piece with ethanol
using a lint-free cloth.
￭ Insert the connecting piece into the suppressor drive so that con-
nector 1 is on top and the 3 pins of the connecting piece fit into
the corresponding recesses on the suppressor drive.
4
Attaching the union nut
￭ Tighten the union nut on the thread of the suppressor drive by
hand (do not use any tools).
3.13.3 Connecting the suppressor
The 3 inlets and outlets of the suppressor units, numbered 1, 2 and 3 on
the connecting piece, each have 2 permanently installed PTFE capillaries.
