3 Installation
883 Basic IC plus
￭￭￭￭￭￭￭￭
13
3
EVA tubing (6.1806.100)
Improves the measuring properties of the
instrument when pulled over the column
input capillary.
4
Eluent input capillary of the suppressor
Labeled in.
5
Detector input capillary of the suppres-
sor
Labeled out.
6
Detector input capillary
7
Detector output capillary
8
PTFE capillary (6.1803.020)
Section, used as regeneration solution aspi-
ration capillary.
9
Pump tubing (6.1826.320)
With orange/yellow stoppers, for the regen-
eration solution.
10
Regeneration solution input capillary
of the suppressor
Labeled regenerant.
11
Regeneration solution output capillary
of the suppressor
Labeled waste reg..
12
Rinsing solution input capillary of the
suppressor
Labeled rinsing solution.
13
Rinsing solution output capillary of the
suppressor
Labeled waste rins..
14
PEEK pressure screw (6.2744.014)
15
PEEK pressure screw, short
(6.2744.070)
16
Tubing olive (6.2744.034)
For connecting capillaries to the aspiration
side of the peristaltic pump.
17
Pump tubing connection (6.2744.180)
With locking nut and filter, for connecting
capillaries to the outlet side of the peristaltic
pump.
18
Coupling (6.2744.040)
19
PTFE capillary (6.1803.040)
Sample aspiration capillary.
20
PTFE capillary (6.1803.040)
Sample output capillary.
