4.11 Metrohm Suppressor Module (MSM)
￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭
30
￭￭￭￭￭￭￭￭
930 Compact IC Flex Oven/SeS/PP (2.930.2500)
2
Installing a new sample loop
￭ Fasten one end of the sample loop to Port 3 using a PEEK pressure
screw (6.2744.010).
￭ Use the second PEEK pressure screw (6.2744.010) to fasten the
other end of the sample loop to Port 6.
4.11 Metrohm Suppressor Module (MSM)
The suppressor drive of the 930 Compact IC Flex can hold various rotors.
The large rotors, such as the MSM‑HC Rotor A (6.2842.000) and the
MSM-HC Rotor C (6.2842.200) can be inserted directly.
The small rotors, such as the MSM Rotor A (6.2832.000) and the MSM-LC
Rotor A (6.2844.000), must first be fitted into the adapter (6.2842.020),
which can then be inserted into the suppressor housing.
A connecting piece (6.2835.010) is used for all rotors for connecting the
Metrohm Suppressor Module (MSM) to the IC system.
6.2842.000
6.2842.020
6.2844.000
6.2842.020
6.2832.000
NOTE
The instruments are supplied without rotor and without adapter.
The suitable rotor and the adapter, if required, must be ordered sepa-
rately.
