Metrohm 930 Compact IC Flex - Overview of the Device; Front; Figure 1 Front

￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭
3 Overview of the device
930 Compact IC Flex Oven/SeS/PP (2.930.2500)
￭￭￭￭￭￭￭￭
9
3 Overview of the device
3.1 Front
Figure 1 Front
1
Bottle holder
2
Column holder
For hanging the separation column (iCol-
umn). With column recognition.
3
Column oven
4
Metrohm Suppressor Module (MSM)
5
Inline filter
6
Injection valve
7
Purge valve
8
Pulsation absorber
9
Base tray
10
High-pressure pump
