Metrohm 930 Compact IC Flex - Figure 16 Column Oven

￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭
6 Operation and maintenance
930 Compact IC Flex Oven/SeS/PP (2.930.2500)
￭￭￭￭￭￭￭￭
63
Figure 16 Column oven
1
Openings
For feeding through the capillaries.
2
Column holder
For hanging the separation column (iCol-
umn). With column recognition.
3
Preheating grooves
For threading in the capillary to be temp-
erature-conditioned.
4
Holder plate
For securing the capillary in place.
5
Recesses
Prevent the capillaries from being pinched.
