Metrohm 930 Compact IC Flex - Inserting the Rotors

￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭
4 Installation
930 Compact IC Flex Oven/SeS/PP (2.930.2500)
￭￭￭￭￭￭￭￭
31
4.11.1 Inserting the rotors
Accessories For this step, you need the following accessories:
￭ For suppression: MSM Rotor A (6.2832.000) or MSM‑HC Rotor A
(6.2842.000), MSM‑LC Rotor A (6.2844.000) or MSM‑HC Rotor C
(6.2842.200) or MSM-HC Rotor C (6.2842.200)
￭ Optional: Adapter (6.2842.020)
￭ Connecting piece (6.2835.010)
Large rotors can be inserted directly into the rotor housing.
CAUTION
The rotor may be destroyed during start-up if not inserted correctly.
Therefore, follow the following instructions exactly.
Inserting large rotors
6.2835.010
4 mm
6.2842.000
6.2842.200
1
Removing the union nut
Loosen the union nut and remove it.
