Figure 28: Pin assignment: SD-/MMC-Card
8.13.6 BOOT-DIP-Switch
During a restart/reset, the BOOT-DIP-Switch is used to determine whether to perform a firmware
download from the SD-/MMC-Card or not. The position of the DIP-Switch is shown in Figure 8.
 BOOT-DIP-Switch in position “ON”  firmware download requested
 BOOT-DIP-Switch in position “OFF”  firmware download not requested
When there is no SD-/MMC-Card in the card slot of the servo drive and the BOOT-DIP-Switch is in the
position “ON” (firmware download requested), the error 29-0 is triggered after a restart/reset.
This error stops all further performances. This means that there is no communication possible via
USB.
Product Manual „Servo drives ARS 2100 SE“ Version 5.0
