Page 81
8.4.4 Cable type and design [X6]
The mentioned cable denominations refer to cables by Lapp. They have proven effective and are
successfully used in many applications. However, similar cables from other manufacturers, for
example Lütze or Helukabel, may also be used.
Caution!
Please comply with the prescribed minimum copper cross-section for cables as per EN
60204-1!
 ARS 2102 SE:
LAPP KABEL ÖLFLEX SERVO 700 CY; 4 G 1,5 + 2 x (2 x 0,75); 12,7 mm, with tinned total Cu
shield
 ARS 2105 SE and ARS 2108 SE:
LAPP KABEL ÖLFLEX SERVO 700 CY; 4 G 2,5 + 2 x (2 x 0,75); 14,9 mm, with tinned total Cu
shield
For highly flexible applications:
 ARS 2102 SE:
LAPP KABEL ÖLFLEX SERVO FD 755 P; 4 G 1,5 + 2 x (2 x 0,75) CP; 14,1 mm, with tinned total
Cu shield for highly flexible use in drag chains
 ARS 2105 SE and ARS 2108 SE:
LAPP KABEL ÖLFLEX SERVO FD 755 P; 4 G 2,5 + 2 x (2 x 0,75) CP; 15,1 mm, with tinned total
Cu shield for highly flexible use in drag chains
Product Manual „Servo drives ARS 2100 SE“ Version 5.0
