4.6 Communication interfaces
4.6.1 USB [X19]
Table 22: Technical data: USB [X19]
Communication interface Values
Function USB 2.0, Slave–Client, 12 MBaud to 480 MBaud
Connector type USB-B, no current consumption from the bus (integrated
power supply)
Communication protocol Metronix specific (generic device)
4.6.2 Ethernet [X18]
Table 23: Technical data: Ethernet [X18]
Communication interface Values
Function Ethernet, 10/100 MBaud (auto select)
Connector type RJ45
4.6.3 CAN-Bus [X4]
Table 24: Technical data: CAN-Bus [X4]
Communication interface Values
CANopen controller ISO/DIS 11898, full CAN controller, max. 1 MBaud
CANopen protokoll as per DS301 and DSP402
4.6.4 SD-/SDHC-/MMC-Card
Table 25: Technical data: SD-/SDHC-/MMC-Card
Communication interface Values
Card type SD, SDHC and MMC
File system FAT12, FAT16 and FAT32
