Table 15: ARS 2102 SE: Rated current for an ambient temperature of  40 °C
Parameter Values
Power stage clock frequency (kHz)
 12
Output current (A
RMS
) 2,5
Max. output current (A
RMS
) 5 7,5 10
Max. allowed time (s) 5 1,3 0,5
Power stage clock frequency (kHz) 16
Output current (A
RMS
) 2,2
Max. output current (A
RMS
) 4,4 6,6 8,8
Max. allowed time (s) 5 1,3 0,5
Power stage clock frequency (kHz) 19
Output current (A
RMS
) 1,9
Max. output current (A
RMS
) 3,8 5,7 7,6
Max. allowed time (s) 5 1,3 0,5
Table 16: ARS 2105 SE: Rated current for an ambient temperature of  40 °C
Parameter Values
Power stage clock frequency (kHz)
 12
Output current (A
RMS
) 5
Max. output current (A
RMS
) 10 15 20
Max. allowed time (s) 5 1,3 0,5
Power stage clock frequency (kHz) 16
Output current (A
RMS
) 4,4
Max. output current (A
RMS
) 8,8 13,2 17,6
Max. allowed time (s) 5 1,3 0,5
Power stage clock frequency (kHz) 19
Output current (A
RMS
) 3,7
Max. output current (A
RMS
) 7,4 11,1 14,8
Max. allowed time (s) 5 1,3 0,5
